Horizontal Bisector

Cut Fresh or Frozen Bread in Half for Your Sandwich Assembly Line

The Horizontal Bisector cuts bread products horizontally into halves, and then transfers them to your sandwich assembly line for processing. With the Horizontal Bisector, you automate and control an additional step in your operation, increasing output and safety while ensuring consistent quality at a lower cost than pre-sliced products. It is available in a single-lane model for frozen sandwiches and a two-lane model, ideal for fresh sandwich lines.

  • Slice up to 100 pieces per minute per lane
  • Single-lane (frozen) and two-lane (fresh) systems available
  • Quickly and easily adjust cut heights for a variety of bread products
  • Can cut in temperatures as low as 20-32 degrees F to handle fresh and frozen products (see model specifics below)
  • Disposable AccuBand® band blades provide optimal quality, consistency and yield while eliminating resharpening and simplifying clean-up



HBS video thumbnail

Automate another step in your sandwich operation with the Horizontal Bisector. Want to confirm performance for your specific needs?
Request a custom demo with your product in our facility today.

Common Food Applications

breadBread

Equipment Information




Specifications

Cutting Zone

4.94” (125.4 mm) wide per lane

Cut Height

.5-3.25” (12.7-38.1 mm)

Lowest Performance Temperature

HBS: 32 degrees F (0 C)
HBZ: 20 degrees F (-6 C)

Electrical

200-575VAC, 50/60 Hz, 1-3 Phase

Transfer Belt Speed

13-40 FPM (4.0-12.2 M/min) with VFD adjustment

Parts & Features

  • AccuBand Blade System
  • Sanitary design with many washdown-rated components

Service & Maintenance

Our expert customer and field service teams work with you to find the solutions you need quickly and efficiently. View all services here

  • Reach a real-life person on our Customer Service team to answer your questions or take a blade or part order.
  • Training programs get your operation up and running fast, and give your operators the know-how to keep it running
  • Our technical service offers a variety of options that meet your needs, including phone and virtual support, scheduled and emergency field service available 24/7
  • Bi-annual flat-rate service plans allow you to plan your scheduled service costs in advance and provide the flexibility of scheduling as many or as little appointments as you need

Additional Information

  • Model HBS: Fresh, two-lane
  • Model HBZ: Frozen, single-lane
  • AccuBand Blades
